Key Product Features

The XEN-S22 (Single Row) Light Bar is perfect for those who require maximum performance in tight fit areas. Our Light Bars are designed to deliver optimum light combination and provide an impressive range of light on all roads. With its sleek screwless design, it not only provides high performance but also a desired finish to your vehicle.

The key features of the XEN-S22 Light Bar includes; the GE (Lexan lens) which is the strongest lens in the market and doesn't yellow over time. The strong mounting bracket includes a rubber dampener that helps to reduce vibration while driving.

Each Light Bar is CISPR 25 Class 3 certified which ensures zero radio or communication interference. The Gore-Tex breather valve ensures 100% pressure equalization and moisture venting. With an IP69K waterproof rating, it's the highest dust and waterproof rating available.

The XEN-Light Bars have a 6500K Kelvin colour temperature that provides bright and clear light. The Fast Fit Wiring Harness included with each Light Bar ensures Plug and Play Installation, and it includes H4 and HB3 high beam adaptors. Moreover, custom light covers are available to protect your Light Bar from any damage.

Choose the XEN-S22 Light Bar for maximum performance, sleek design, and ultimate convenience.

Technical Specifications

LED

20 X OSRAM 5w

Effective Lumens

9,520 LM

Lumination Distance

1056 M

1 LUX @

528 M

Voltage

9-36V DC

Warranty

3 YEARS

Power

100W

Beam Pattern

SPOT, FLOOD BEAM

Lense

GE LENSE

IP Rating

IP68 & IP69K

Colour Temperature

6,500K

Connections

INCLUDED

Life Time

50,000 + Hours

Day Time Running Lights

NO

Wiring

WIRING HARNESS INCLUDED

ISO Lux Graph

Dimensions
